Breeze T-Bolt Spring-Loaded Heavy Duty B9224-0375 3 3/4 - 4 1/16 Inch Range, 3/4" 301 SS Band fullscreenView Full

HD Spring-Loaded T-Bolt B9224-0388 3.88" - 4.12" Range, 3/4" 301 SS Band

Pricing:
Item #: B9224-0388
Availability: In Stock
Min Qty: 2
Qty:
-
+
Total = $13.96
Share:
Product Details
  • Used for industrial, marine and vehicle applications to compensate for thermal expansion of hose or fitting connections
  • B9224 - Heavy duty large spring with washers
  • Floating bridge liner
  • Per SAE standard J1508 Type "SLTB"
Specs
Band Material: 301 SS
Screw Material: Zinc Plated Carbon Steel
Band Width: 3/4"
Min. Inches: 3.88
Max. Inches: 4.12
Min. mm: 98.5
Max. mm: 104
Torque Range: 150 in/lbs
Hex Screw: 1/2" Nut
Pack: 1
Unit: EA
Type: Constant Tension Clamps
Clamp Durability: High Pressure|Automotive|Fluxuating Temperatures|High Vibration|Large Diameter|Soft Hose|Industrial|Commercial|High Strength|Diesel|Pipes|Hose
Max. Inches (Decimal): 4.12
Min. Inches (Decimal): 3.88
Environment: Dry|Indoors
